SSG000\08
12-2005
60
BCK IN tE>>--------------------------------------------------------------------------- OFF ON
BCK OUT tE>> ------------------------------------------------------------------------ OFF ON
tE>>b 0.06...10.00 s ----------------------------------------
BF IE>> ----------------------------------------------------------------------------OFF
ON
BCKRUN IE>>------------------------------------------------------------------------- OFF ON
IE>>> --------------------------------------
0.002...10.00 IEn---------------------------
tE>>> ------------------------------------------- 0.04...10.00 s ----------------------------
BCK IN tE>>> ------------------------------------------------------------------------- OFF ON
BCK OUT tE>>> ----------------------------------------------------------------------- OFF ON
tE>>>b 0.06...10.00 s ----------------------------------------
BF IE>>> ---------------------------------------------------------------------------- OFF
ON
BCKRUN IE>>> ----------------------------------------------------------------------- OFF ON
59N,BANK A(B)59N,BANK A(B)
59N,BANK A(B)59N,BANK A(B)
59N,BANK A(B) UE> ----------------------------------------- 0.01...0.20 UEn ----------------------------
tUE> --------------------------------------------- 0.05...180 s ----------------------------
BF UE> --------------------------------------------------------------------------- OFF ON
UE>> ---------------------------------------- UE>...0.50 UEn ----------------------------
tUE>> --------------------------------------------- 0.05...180 s ----------------------------
BF UE>> --------------------------------------------------------------------------- OFF ON
67N,BANK A(B)67N,BANK A(B)
67N,BANK A(B)67N,BANK A(B)
67N,BANK A(B) INDEP IED> ---------------------------------- 0.002...10.00 IEn ----------------------------
tED> 0.05...180 s -------------------------------------------
DEP --------
DEP A ---------------------------------- DEP B -------------------------- DEP C
IEDS 0.002...0.200 IEn-------------------------------------
tEDS 0.10...60.0 s ------------------------------------------
UED> 0.004...0.500 UEn------------------------------------
θ
E> 0...359° --------------------------------------------------
β> 0...180° --------------------------------------------------
BF IED> ----------------------------------------------------------------------------OFF ON
BCKRUN IED> ------------------------------------------------------------------------ OFF ON
IED>> ---------------------------------------- 0.002..10.00 IEn ----------------------------
tED>> ---------------------------------------------- 0.05...180 s ----------------------------
UED>> -------------------------------------- 0.004...0.500 UEn ----------------------------
θE>> ------------------------------------------------- 0...359°----------------------------
β>> ------------------------------------------------- 0...180°----------------------------
BCK IN tED>> ------------------------------------------------------------------------- OFF ON
BCK OUT tED>>----------------------------------------------------------------------- OFF ON
tED>>b 0.07...180.00 s---------------------------------------
BF IED>> ---------------------------------------------------------------------------- OFF
ON
BCKRUN IED>> ------------------------------------------------------------------------OFF ON
IED>>> --------------------------------------- 0.002...10.00 IEn ----------------------------
tED>>> ----------------------------------------------0.05...180 s ----------------------------
UED>>> -------------------------------------- 0.004...0.500 UEn ----------------------------
θE>>> ------------------------------------------------- 0...359°----------------------------
β>>> ------------------------------------------------- 0...180°----------------------------
BCK IN tED>>> ----------------------------------------------------------------------- OFF ON
BCK OUT tED>>> --------------------------------------------------------------------- OFF ON
tED>>>b ---------------------------- 0.07...180.00 s---------------------------
BF IED>>> ----------------------------------------------------------------------------OFF
ON
BCKRUN IED>>> --------------------------------------------------------------------- OFF ON
BLOCK,BANK A(B)BLOCK,BANK A(B)
BLOCK,BANK A(B)BLOCK,BANK A(B)
BLOCK,BANK A(B) tB --------------------------------------------- 0.10...10.0 s ----------------------------
tF --------------------------------------------- 0.00...1.00 s ----------------------------
EN PULSE IN -------------------------------------------------------------------------------- OFF ON
EN PULSE OUT ----------------------------------------------------------------------------- OFF ON
BF,BANK A(B)BF,BANK A(B)
BF,BANK A(B)BF,BANK A(B)
BF,BANK A(B) tBF --------------------------------------------- 0.05...10.0 s ----------------------------
BCKRUN,BANK A(B) BCKRUN,BANK A(B)
BCKRUN,BANK A(B) BCKRUN,BANK A(B)
BCKRUN,BANK A(B) tBRUN --------------------------------------------- 0.00...60.0 s
