TIELBURGER tk 520 - Page 15

Tighten all bolts.
Turn the nut with washer on the bolt.
Push the bolt with washer through the hole.
Remove the castors.
Installation
15
A B C
Push the bolt with washer through the drilled
hole and screw it into the spacer.
2x M8 x 16
2 x 8.4-25-2
2x M8 x 20
2x
2 x 8.4-25-2
2 x 8.4-25-2
2x M8
