Parts Section 5-7
TRACTOR MOUNT KIT - HYDRAULICS 5101E
ITEM PART NO. QTY. DESCRIPTION
1 06300033 1 MAIN FRAME
2 06300088 1 MNT,HTDRO TANK,NHT6010
3 06700090 ASSY HYDRAULIC TANK
4 23152 1 PUMP
5 06510083 1 SOLENOID BRAKE VALVE
6 34117 1 ELBOW 1”MORB X 1”MORB90
7 33554 1 ELBOW 1”MORB X MJIC45
8 21644 2 CAPSCREW - 3/8” X 5”
9 22016 2 FLATWASHER - 3/8”
10 30255 3 SPACER,1-1/4OD X 3/4ID X 3/4
11 21627 2 NYLOCK NUT,3/8 NC
12 34309 1 BALL VALVE,1 1/2 FOR
13 34655 1 ELBOW,1 1/2 ORB x 1 1/2 MJ
14 06506039 1 HOSE/TUBE,#24 x 65(24FJX x 20FL)
15 06506023 1 HOSE/TUBE ,1 x 62(20FLG x 1FJX)
16 06500398 1 HOSE,#16x114(16FJXx16FJX90)
17 34076 1 CLAMP KIT - 1”
18 06505017 1 CLAMP KIT - 1-1/4”
19 34626 2 TUBE / CLAMP BRACKET
20 TF4852 2 FLANGE KIT - #20
21 34064 1 ADAPTER - 1-1/4” X 1”
22 33555 2 ADAPTER 1”MORB X 1”MJIC
23 1 HOSE (PRESSURE)
24 1 HOSE (RETURN)
25 22421 2 CAPSCREW, 16MM X 40MM
26 31732 1 CAPSCREW, 16MM X 70MM
** 6T3200 8 SPLIT HOSE (NOT SHOWN)
** 6T1823 24 ZIP TIE (NOT SHOWN)
** 6T1822 14 ZIP TIE (NOT SHOWN)
NOTE: Band hoses together with zip ties wherever loose. Where hoses
may contact the frame or other edges, wrap with split hose and
secure with hose clamps or zip ties.
