Cheetah Common Section 6-3
PARTS SECTION TABLE OF CONTENTS
SECTION PAGE
TRACTOR SPECIFIC PARTS:
CHEETAH QUICK COUPLERS 6-4
CHEETAH BOOM ARM ASSY 6-6
CHEETAH ROTARY MOWER DECK 6-8
CHEETAH ROTARY PIVOT ASSY. 6-10
DAN FOSS VALVE BREAKDOWN 6-12
HUSCO VALVE BREAKDOWN 6-14
CHEETAH ROTARY MOTOR 6-20
ROTARY SPINDLE ASSY. 6-22
CHEETAH FLAIL HEAD ASSY. 6-24
CHEETAH FLAIL - CUTTER SHAFT ASSY. 6-26
CHEETAH FLAIL MOTOR 6-28
CHEETAH CYLINDER BREAKDOWNS 6-30
RESERVOIR TANK FILTER ASSEMBLY 6-34
BRAKE VALVE ASSEMBLY W/METRI PAK 6-35
BOOM TRAVEL LOCK 6-36
SOLENOID BRAKE VALVE HYDRO SCHEMATIC 6-37
JOYSTICK SWITCH BOX SERVICE PARTS 6-38
JOYSTICK SCHEMATIC 6-39
HUSCO CONTROLS SWITCHBOX 6-40
OPTIONAL PUMP GUARD KITS 6-42
OPTIONAL GRILL GUARD 6-43
TROUBLSHOOTING 6-44
HYDRAULIC - TROUBLSHOOTING GUIDE 6-46
ELECTRICAL - TROUBLSHOOTING GUIDE 6-47
