Parts Section 5-15
TRACTOR MOUNT KIT - HYDRO, WHEEL WELL TANK
ITEM PART NO. QTY. DESCRIPTION
1 06300033 1 MAIN FRAME
2* 1 1” HOSE
3* 1 1” HOSE
4 33555 2 ADAPTER,1MORB x 1MJIC
5 * REF BRAKE VALVE - REFER TO MAIN FRAME PARTS
6 34117 1 ELBOW,1MORB x 1MORB90
7 06506023 1 HOSE/TUBE,1 x 62”
8 33554 1 ELBOW,1MORB x 1MJIC45
9 22421 1 CAPSCREW,16MM x 40MM
10 34076 1 CLAMP KIT,1”
11 34626 1 TUBE/CLAMP BRACKET
12 30255 1 SPACER
13 TF4852 2 FLANGE KIT,#20
14 06500408 1 HOSE,1-1/2 x 92”
15 32382 1 HOSE BRACKET
16 34710 1 ADAPTER,1-1/2ORB x 1-1/2MJ
17 34309 1 BALL VALVE,1-1/2”
18 06503083 1 ADAPTER,1-1/2ORB x 1-1/2ORB
19 06503084 1 ELBOW,1-1/2FOR x 1-1/2FOR
20 * REF AXLE BRACE,RH - REFER TO MAIN FRAME PARTS
21 * REF AXLE BRACE,LH - REFER TO MAIN FRAME PARTS
22 * REF TANK,ASSY - REFER TO MAIN FRAME PARTS
23 06505077 1 BREATHER CAP,O-RING
24 34064 1 ADAPTER,1-1/4MOR x 1MJIC
25 06500422 1 HOSE,1 x 126”
