Parts Section 5-17
BOOM MOUNT KIT - BOOM SWIVEL / BOOM REST
ITEM PART NO. QTY. DESCRIPTION
1 06310023 1 BOOMREST,STD,3PNT
2 06310030 1 MNT BRKT,BOOM,GREASELESS,CHET
3 06700056 1 SWIVEL,ASSY,GREASELESS,CHET
4 34275 1 CYL,2 1/2X11 1/2,2500 PSI
5 06420013 1 PIN,1.5x18.88,W/.47 HOLE,NIT
6 6T3001 1 PIN,INNR DRFT BM 1-1/2X15-3/4
7 TB1036 1 PIN,SEC BOOM SWIV 1X4-11/16
8 TB1031 1 PIN,PVT ASSY 1 X 4 LOCKINGHEAD
9 TB3033 1 CLEVIS,W/SPHERICAL BEARING
10 TF1120 2 PIN,(CAPPED),1-1/8 X 3-7/8
11 TF1143 3 PIN,LYNCH 7/16 X 2
12 06420114 1 SPACER,2.25x1.25x1.38,TAPPED
13 6T2272 1 SETSCREW,3/8 X 1/2 NC
14 21635 1 CAPSCREW,3/8 X 2-1/4 NC
15 21627 1 NYLOCK NUT,3/8 NC
17 21688 2 CAPSCREW,7/16 X 3-1/4 NC
18 06520049 1 BEARING,WASHER,SWING
20 21677 3 NYLOCK NUT,7/16 NC
21 21835 2 CAPSCREW,3/4 X 2-3/4 NC
22 6T2607 2 FLATWASHER,3/4,CUT
23 22021 3 FLATWASHER,3/4
24 21993 2 LOCKWASHER,3/4,GR 8
25 21825 2 HEX NUT,3/4 NC
26 6T3004 1 R-CLIP(HAIRPIN COTTER,3/16)
30A * REF REFER TO MAIN FRAME PARTS
30B * REF REFER TO MAIN FRAME PARTS
31 06499004 1 BEARING,.1.5x1.25x1,COMP
32 33464 1 PIN,1.00 x 5.63, W/HOLE
33 TB3010 1 BUSHING,1
35 06310027 1 BOOMREST,CHET,3PNT
36 21846 1 CAPSCREW,3/4 X 9 NC
38 21827 1 NYLOCK NUT,3/4 NC
