Cheetah Common Section 6-7
ITEM PART NO. QTY. DESCRIPTION
1 31153A 1 MAIN BOOM ARM
2 31154A 1 SECONDARY BOOM ARM
3 33702 1 CYLINDER
4 33703 1 CYLINDER
5 33731 1 CYLINDER
6 23888 1 ACCUMULATOR BRACKET
7 33470 1 ACCUMULATOR
8 33442 1 PIN
9 33443 1 PIN
10 06420053 1 PIN
12 TB1033 4 PIN, CLEVIS
13 06537021 8 ROLL PIN
14 6T3014 3 ROLL PIN
15 33440 4 TUBE CLAMP KIT
16 33503 1 PIN
17 TF1143 1 LYNCH PIN
18 TB3033 1 CLEVIS
19 TB3010 3 BUSHING
20 33174 2 PREFORMED TUBE
21 33181 2 PREFORMED TUBE
22 33175 1 PREFORMED TUBE
23 33176 1 PREFORMED TUBE
24 33178 1 PREFORMED TUBE
25 33177 1 PREFORMED TUBE
26 33179 1 PREFORMED TUBE
27 33180 1 PREFORMED TUBE
28 33182 1 PREFORMED TUBE
29 33183 1 PREFORMED TUBE
30 24724 2 SWIVEL
31 28917 1 ADAPTER
32 32821 1 TEE
33 32810 7 ELBOW
34 33395 2 HOSE
35 33449 1 HOSE
36 33450 1 HOSE
37 33504 2 HOSE
38 * REF REFER TO PARTS SECTION
39 33451 1 HOSE
40 33452 1 HOSE
41 * REF REFER TO MAIN FRAME PARTS
42 * REF REFER TO PARTS SECTION
43 21629 2 CAPSCREW - 3/8 X 3/4
44 21988 2 LOCKWASHER - 3/8
45 21688 2 CAPSCREW - 7/16 X 3 1/4
46 21989 2 LOCKWASHER - 7/16
47 21675 2 HEX NUT - 7/16
48 33399 1 ELBOW
49 * REF REFER TO PARTS SECTION
50 * REF REFER TO PARTS SECTION
51 34275 1 SWIVEL CYL.
52 31329 1 ADAPTER 1/2” ORB X 1/2” ADJ
53 06510050 1 TRAVEL LOCK VALVE
54 33271 1 ADAPTER 1/2”OR X 3/8” MJ
55 33513 1 DECAL KIT (NOT SHOWN)
CHEETAH BOOM ARM ASSEMBLY
