Cheetah Common Section 6-19
4SP HUSCO LIFT VALVE - OPEN CENTER (27671)
ITEM PART NO. QTY DESCRIPTION
1 TB1017S 1 INLET END COVER
2 TB1701 1 END COVER, OPEN CENTER
3 TB1017P 1 VALVE SECTION (SINGLE ACTING, SPRING DETENT)
4 TB1017N 1 VALVE SECTION (DOUBLE ACTING, CENTER SPRING)
5 TF3009 1 VALVE SECTION (DOUBLE ACTING, DETENT - FLOAT)
6 TB1017Q 1 VALVE SECTION (DOUBLE ACTING, SPRING METERED)
7 N/A - N/A
8 TB1017K 1 RELIEF VALVE, 2150 PSI
9 TB1017J 1 RELIEF VALVE, 1800 PSI
10 TB1017H 1 RELIEF VALVE, 1750 PSI
11 06502037 1 RELIEF VALVE, 2600 PSI
12 06502003 1 RELIEF VALVE, 2500 PSI
13 TB1017F 1 RELIEF VALVE, 1500 PSI
14 TB1017F 1 RELIEF VALVE, 1500 PSI
15 TB1017H 1 RELIEF VALVE, 1750 PSI
16 TB1017A 4 VALVE SEAL KIT (FOR ONE SECTION)
16A 2 WIPER
16B 2 O-RING SMALL
16C 1 O-RING LARGE
16D 1 SPRING
16E 1 PUCKET
17 TB1017L 4 LEVER KIT (FOR ONE SECTION)
17A 1 LEVER KNOB
17B 1 LEVER
17C 2 LEVER WASHER
17D 1 LEVER CLIP
17E 2 LINKAGE
17F 1 LEVER PIN
17G 1 ROLL PIN
17H 1 LEVER BOOT
17J 1 LEVER BOLT
17K 1 LEVER DUST COVER
17L 1 LEVER NUT
18 TB1017U 1 TIE ROD KIT
19 24214 1 O-RING, LARGE
