Cheetah Common Section 6-33
CHEETAH CYLINDER BREAKDOWNS
3 1/2” X 14” CYLINDER # 33703
ITEM PART NO. QTY. DESCRIPTION
1 33822 1 PISTON ROD
2 33823 1 CYLINDER TUBE
3 33824 1 CYLINDER BUTT
4 33825 1 CYLINDER GLAND
5 33826 1 PISTON
6 33827 1 LOCK NUT
7 33829 4 TIE-ROD ASSY
8 6T0178 1 CLEVIS ASSY
33832 AVAIL SEAL KIT
9 * 1 U-CUP
10 * 1 WIPER
11 * 1 CROWN SEAL
12 * N/A N/A
13 * 1 O-RING
14 * 2 O-RING
15 * 1 BU-WASHER
4” X 14” CYLINDER # 33702
ITEM PART NO. QTY. DESCRIPTION
1 33814 1 PISTON ROD
2 33816 1 CYLINDER TUBE
3 6T0169 1 CYLINDER BUTT
4 6T0171 1 CYLINDER GLAND
5 33817 1 PISTON
6 6T0175 1 LOCK NUT
7 33819 4 TIE-ROD ASSY
8 6T0172 1 CLEVIS ASSY
33821 AVAIL SEAL KIT
9 * 1 U-CUP
10 * 1 WIPER
11 * 1 CROWN SEAL
12 * 1 BEARING RING
13 * 1 O-RING
14 * 2 O-RING
15 * 1 BU-WASHER
