Parts Section 5-19
ITEM PART NO. QTY. DESCRIPTION
1 32165 1 LEFT HAND DRAFT BEAM
2 30481 1 INBOARD CYLINDER
3 32215 1 OUTBOARD CYLINDER
4 TF4500A 1 PIVOT ARM
5 TF4506B 1 LIFT ARM - LH
6 TF4507B 1 LIFT ARM - RH
7 30126B 2 PIN
8 6T3001 1 PIN
9 TF4519 2 PIN
10 6T3207 1 GREASE ZERK
11 6T3211 4 GREASE ZERK
12 TB1033 3 CLEVIS PIN
13 06537021 6 ROLL PIN
14 6T3005 1 CYLINDER PIN
15 6T3004 1 R-CLIP
16 6T2614 1 FLATWASHER - 1"
17 TB3010 2 BUSHING
18 23724 3 SPACER - AS NEEDED
19 22973A 2 SHIM
21 22076 2 SPACER - AS NEEDED
22 22077 2 SPACER - AS NEEDED
23 34244 3 ELBOW 1/2 ORB X 1/2 FOR
24 34396 3 ADAPTER RESTRICTOR
25 6T4258 1 BREATHER
26 22847 2 BOSS
29 21635 2 CAPSCREW - 3/8" X 2 1/4"
30 21988 2 LOCKWASHER - 3/8"
31 21625 2 HEX NUT - 3/8"
32 21688 3 CAPSCREW - 7/16" X 3 1/4"
33 21989 3 LOCKWASHER - 7/16"
34 21675 3 HEX NUT - 7/16"
35 * REF. MAIN FRAME - REFER TO MAIN FRAME PARTS
36 06520004 1 CLEVIS
37 06531001 1 JAM NUT
DRAFT BEAM - LEFT HAND
11-20-01
