Parts Section 5-21
ITEM PART NO. QTY. DESCRIPTION
1 34374 1 COOLER ASSY
* TF4619 AVAL COOLER
* TF4614 AVAL COOLER COIL
2 32053 1 COOLER SHELF
3 30185A 4 CANOPY BRACKET - 2INSIDE, 2 OUTSIDE OF R.O.P.S.
4 32495 2 ROLL BAR BRACKET
5 32499 4 RETAINING PLATE
6 21741 4 CAPSCREW 1/2" X 4"
7 21743 4 CAPSCREW 1/2" X 5"
8 21990 16 LOCKWASHER 1/2"
9 21725 16 HEX NUT 1/2"
10 34401 1 HOSE 1” x 218”
11 34402 1 HOSE 1” x 238”
12 21638 1 CAPSCREW 3/8" X 3"
13 22016 1 FLATWASHER 3/8"
14 TB3031 1 HOSE CLAMP
15 21627 1 NYLOCK NUT 3/8"
16 28053 1' TRIMLOCK
17 27053 AVAL FAN ASSY
* TF4615 2 BLADE
* TF4616 2 GAURD/MOTOR BRKT
* TF4618 2 MOTOR
NOTE: WHEN CANOPY OPTION IS USED, ONLY THE TWO BRACKETS ON
THE INSIDE OF THE R.O.P.S. WILL BE USED. (REFERENCE #3)
HYDRAULIC COOLER - WOC 5520
11-20-01
