Triple Gang Flail Common Section 6 - 77
ITEM PART NO. QTY. DESCRIPTION
* 06504013 AVAIL MOTOR ASSEMBLY 350 - TSF
1 06504039 1 SHAFT END COVER
2 06504040 1 PORT END COVER
3 06504041 1 GEAR HOUSING
4 06504042 1 MATCHED GEAR SET
5 TF4402 1 BALL BEARING
6 06504043 4 CAP SCREW
7 06504044 2 SET SCREW
8 06504028 1 KEY
9 06504045 4 DOWEL PIN
10 1 NAMEPLATE
11 763759 2 THRUSTPLATE
12 02961940 1 HEX PLUG
13 TF4401 1 SNAP RING
14 06504049 1 LIP SEAL (INCLUDED IN SEAL KIT)
15 TF4410 2 GASKET SEAL (INCLUDED IN SEAL KIT)
16 06504046 4 SIDE SEAL (INCLUDED IN SEAL KIT)
17 06504047 4 END SEAL (INCLUDED IN SEAL KIT)
18 TF4407 2 BACK-UP SEAL (INCLUDED IN SEAL KIT)
19 06504048 1 SEAL RETAINER
20 6T5809 2 CHECK ASSEMBLY
21 02961917 4 WASHER
* 06504023 AVAIL SEAL KIT (INCLUDES 14, 15, 16, 17, AND 18)
SIDE DECK MOTOR – HIGH PRESSURE
