Tiger JD 5520 - Page 187

Triple Gang Flail Common Section 6 - 81
HYDRAULIC LIFT CYLINDER
3” X 12” CYLINDER # 32215
ITEM P/N QTY DESCRIPTION
1 6T0167 1 CYLINDER BUTT
2 6T0170 1 CYLINDER GLAND
3 6T0178 1 CLEVIS END
4 6T0204 1 CYLINDER TUBE
5 6T0203 1 PISTON ROD
6 6T0173 1 PISTON
7 6T0179 1 LOCKNUT
8 6T0205 1 TIE ROD ASY
6T0187 AVAIL SEAL KIT
9 2 O - RING
10 2 BACK - UP WASHER
11 1 O - RING
12 2 BACK - UP WASHER
13 1 O - RING
14 1 U - CUP
15 1 WIPER
3” X 8” CYLINDER # 31211
ITEM P/N QTY DESCRIPTION
1 6T0167 1 CYLINDER BUTT
2 6T0170 1 CYLINDER GLAND
3 6T0178 1 CLEVIS END
4 23870 1 CYLINDER TUBE
5 23869 1 PISTON ROD
6 6T0173 1 PISTON
7 6T0179 1 LOCKNUT
8 21749 4 TIE ROD ASY
6T0187 AVAIL SEAL KIT
9 2 O - RING
10 2 BACK - UP WASHER
11 1 O - RING
12 2 BACK - UP WASHER
13 1 O - RING
14 1 U - CUP
15 1 WIPER
