Parts Section 5-7
TRACTOR MOUNT KIT - MAIN FRAME, WOC, 5520
ITEM PART NO. QTY. DESCRIPTION
1 34388 1 RESERVOIR TANK
2 34066 1 IN-TANK FILTER ASSY.
3 21627 4 NYLOCK NUTS
4 6T4197 1 PIPE PLUG
5 6T4200 3 PIPE PLUG
6 6T4201 2 PIPE PLUG
7 32262 1 MAIN FRAME
8 34404 1 AXLE BRACE RIGHT HAND
9 34403 1 AXLE BRACE LEFT HAND
11 TF4253LA 1 TRAVEL LOCK BRACKET LH
12 TF4253RA 1 TRAVEL LOCK BRACKET RH
13 TF4250 2 TRAVEL LOCK PIN W/ CHAIN
14 6T3004 2 R-CLIP
15 32323 1 SOLENOID BRACKET RH
16 32324 1 SOLENOID BRACKET LH
17 31004 1 PRESSURE CAP ASY.
18 21732 4 CAPSCREW 1/2” X 1 3/4”
19 33480 1 PUMP MOUNTING BRACKET
20 6T0375B 1 DRIVE SHAFT COUPLER
21 34235 1 PUMP DRIVE SHAFT
22 6T0389 1 CRANKSHAFT ADAPTER
23 32583 1 CRANKSHAFT SPACER
24 6T1209 2 TANK SIGHT GLASS
25 TF4450 1 HYDRAULIC PUMP
29 21990 4 LOCKWASHER 1/2"
30 21725 4 HEX NUT 1/2"
31 6T2530 8 CAPSCREW 16MM X 65MM (2.0 PITCH)
32 6T2625 8 LOCKWASHER 16MM
33 31731 8 CAPSCREW 20MM X 50MM
34 24881 8 LOCKWASHER 20MM
35 22014 1 FLATWASHER 1/4"
36 21986 1 LOCKWASHER 1/4”"
37 32519 1 WING NUT 1/4”"
44 6T2501 4 CAPSCREW 10MM X 60MM
45 32691 4 LOCKWASHER 10MM
46 21989 4 LOCKWASHER 7/16"
47 21992 12 LOCKWASHER 5/8"
48 21775 4 HEX NUT 5/8"
49 21784 4 CAPSCREW 5/8" X 2 1/4"
50 21831 8 CAPSCREW 3/4" X 1 3/4"
51 21781 8 CAPSCREW 5/8" X 1 1/2"
53 21580 2 CAPSCREW 5/16" X 1"
54 22015 2 FLATWASHER 5/16"
55 21987 2 LOCKWASHER 5/16"
56 21575 2 HEX NUT 5/16"
57 21993 8 LOCKWASHER 3/4"
58 6T2260 4 CAPSCREW 7/16" X 1 1/2" CUT
59 06537004 4 WASHER,NEOPRENE,.75x1.25x.19
60 24937 4 FLATWASHER
10-2-02
