Parts Section 5-13
ITEM PART NO. QTY. DESCRIPTION
1 27411 1 VALVE
2 6T1251 4 CABLE CONTROL BOX
3 24943 4 CABLE CONTROL
4 23865B 1 CABLE CONTROL STAND
5 31297 1 DOUBLE SWITCH BOX
6 34267 1 VALVE MOUNTING PLATE
7 34360 1 VALVE MOUNTING STRAP
8 6T3927 1 CONTINUOUS SOLENOID
9 6T3957 1 CIRCUIT BREAKER
11 6T4411 4 CABLE CONTROL CLEVIS
12 6T3017 4 ROLL PIN
13 6T3200 1 SPLIT HOSE
14 TB3440 8" TRIM LOCK
15 34400 4 HOSE 1/4” X 116”
16 33663 2 HOSE 1/4” X 122
17 34240 1 HOSE 1/2” X 63”
18 34241 1 HOSE 1/2” X 29”
19 34350 1 HOSE 1/2” X 45”
20 34351 1 HOSE 1/2” X 55”
21 32872 1 TEE SWIVEL
22 TB1095 2 SWIVEL
23 TB1094 1 SWIVEL
24 27145 1 SWIVEL
25 21631 1 CAPSCREW 3/8" X 1 1/4"
26 21632 4 CAPSCREW 3/8" X 1 1/2"
27 21635 3 CAPSCREW 3/8" X 2 1/4"
28 21633 2 CAPSCREW 3/8" X 1 3/4"
29 21627 2 NYLOCK NUT 3/8"
30 22016 3 FLATWASHER 3/8"
31 21988 8 LOCKWASHER 3/8"
32 21625 8 HEX NUT 3/8"
33 21986 9 LOCKWASHER 1/4"
34 21500 8 HEX NUT 1/4"NF
35 21547 3 CAPSCREW 1/4" X 8"
36 21525 5 HEX NUT 1/4"
37 6T2491 1 CAPSCREW 8MM X 30MM
38 21529 2 CAPSCREW 1/4” X 3/4”
39 32359 2 MACHINE SCREW #8
40 32360 2 LOCKWASHER #8
41 32361 2 HEX NUT #8
42 6T2619 1 LOCKWASHER 8MM
LIFT VALVE - 4SP CAB 5520
10-2-02
