Parts Section 5-15
ITEM PART NO. QTY. DESCRIPTION
1 27411 1 VALVE
2 32429 1 VALVE STAND
3 TB1017L 4 LEVER ASSY.
4 27400 1 SWITCH BOX
5 33367 1 HOSE 1/4” x 49”
6 34397 1 HOSE 1/4” x 109”
7 34399 2 HOSE 1/4” x 68”
8 34398 2 HOSE 1/4” x 90”
9 33746 3 HOSE 1/2” x 109”(1/2”FJ90x1/2”FJ)
10 6T3198 10 HOSE COVER
11 31171 1 PIPE PLUG
12 30548 3 ADAPTER 1/2”FP X M22
13 32678 1 ADAPTER 5/8”ORB X 1/2”FOR
14 33293 1 ELBOW 1/2”MOR X 1/2”MJIC90
15 33383 2 ELBOW 5/8”MORB X 1/2”MJX90
16 * REF. CAPSCREW - REFER TO MAIN FRAME PARTS
17 * REF. LOCKWASHER - REFER TO MAIN FRAME PARTS
18 * REF. HEX NUT - REFER TO MAIN FRAME PARTS
19 21631 4 CAPSCREW - 3/8" X 1 1/4"
20 21988 4 LOCKWASHER - 3/8"
21 21625 4 HEX NUT - 3/8"
22 27979 1 HOSE COVER TO COVER VALVE
23 6T3927 1 CONTINUOUS SOLENOID
24 21534 2 CAPSCREW 1/4” X 2”
25 21986 2 LOCKWASHER 1/4”
26 21525 2 HEX NUT 1/4”
27 6T3957 1 CIRCUIT BREAKER, 30 AMP
28 32359 2 MACHINE SCREW #8
29 32360 2 LOCKWASHER #8
30 32361 2 HEX NUT #8
31 * REF. MAIN FRAME - REFER TO MAIN FRAME PARTS
32 * REF. TRAVEL LOCK - REFER TO MAIN FRAME PARTS
LIFT VALVE - 4SP WOC 5520
11-20-01
