TIMBERWOLF
TW PTO 150H
2
Serial No. Location
The serial number can be
found on the identification
plate located on the rotor
housing
The Timberwolf PTO/150H brushwood chipper, is designed to chip solid wood material including
timber branches, saplings and brushwood up to a maximum of 150mm in diameter. It is capable
of chipping over 3 tonnes of brushwood per hour.
The Timberwolf PTO/150H brushwood chipper is required to be securely 3 - point coupled with
a 25-60hp tractor unit with 540rpm PTO when in use. Power from the attached tractor unit is to
be supplied to the chipper via PTO drive shaft.
DIMENSIONS
2035 mm (1440mm with discharge removed)
2880 mm (1775 mm with feed tray folded)
1110mm
TIMBERWOLF TW PTO/150H SPECIFICATION
Power source: Tractor PTO Drive
PTO speed: 540rpm
Required engine power: 25 - 60hp
3 - Point Mounting Cat. 1 / 2
Overall weight: 400kg
Type of feed: Hydraulic
Maximum diameter material: 150 mm (6”)
Material processing capacity: 3 tonnes/hr
The Timberwolf TW PTO/150H
