Timeguard TG77 - Programming ON;OFF times

7 8
6. Programming
ON/OFF times
Note: 20 ON/OFF programmes are available.
Any number up to 20 can be programmed,
unused programmes must be left blank (– – : – –)
and not programmed with zeros.
Decide what ON/OFF times you would like to
programme and which days they will operate on.
You are able to programme ON/OFF times to operate
over the following days/day groups (shown in order
of presentation on the TG77 programming screen);
The example programmed times used below are:
ON at 12:10 and OFF at 16:05. The example days/day
group used is: MON, TUE, WEDS.
MO TU WE TH FR SA SU (24 hour operation)
MO THROUGH TO SU (individual days)
MO TU WE TH FR
SA SU
MO TU WE TH FR SA
MO WE FR
TU TH SA
MO TU WE
TH FR SA
