Thermostat
• This thermostat is of Class II Construction and must not be earthed
• Connection: 2 wire
• Installation Type: Using either the surface mount box
supplied or a BS flush mount wall box
(min 35mm depth)
• Wi-Fi Protocol: 802.11b/g/n
• Network Protocol: IPv4 TCP
• Frequency Range: 2.412 – 2.484 GHz
• 5 Operating Modes: Permanent ON or OFF, Auto Timed,
Frost and Holiday
• Programmes: 6 timed periods per day, with weekly repeats
• Back Light: Yes
• Operating Temperature Range: 0°C to +40°C
• Set Temperature Range: Minimum +5°C to maximum +35°C
• Temperature Adjustment: 0.5°C steps
• Swing 0.5 or 1.0 C
• CE Compliant
• Dimensions (HxWxD): 90mm x 90mm x 46mm
TRTWIFI Thermostat – Front View
The heating
symbol will show
when heat is
demanded
The override
symbol will
show when
temperature has
been manually
changed
+/- setting
buttons
The Wi-Fi icon
will show when
the device is
connected to
the internet
The frost symbol
will show when
frost protection
mode is active
Holiday
mode icon
Auto mode
icon
5°C to 35°C set
temperature range
