Audio Processor TPT-SP4BT
1. REMOTE OUT / SEQUENCER: This feature allows sequenced startup
of other products through your remote connecon (REM). Make the
connecon using a minimum 18 AWG cable. Each connecon can be
congured, enabled or disabled by the applicaon or SMC control.
2. REM IN: Use this connecon for automac processor acvaon when
turning on the radio/player. Connect the remote output of the radio/
player through a cable of at least 18 AWG.
3. NEGATIVE POWER CONNECTOR (GND): Connect to the negave terminal
of the baery through a minimum 13 AWG cable.
Processor Overview
6 7 1098 11
1 2 3 4 5
