TIMPANO TPT-SP4BT - Installation

6
SEQUENCER
Outputs for remote
acvaon
Baery
Install it close
to the baery
(12” max.)
Radio / Player
TIMPANO
- B
- A
INPUT A
INPUT B
HIGH INPUT
(AUTO TURN ON)
BLUE WIRE
WIRE GRAY
AUDIO OUTPUT
S3
S2
S1
Installation
Specicaon of the cables and fuse for proper installaon:
▪ Power connectors (posive/negave) .................................
▪ Remote connectors (REM IN / REM OUT ) ..........................
▪ Fuse ......................................................................................
13 AWG
18 AWG
1A
POWER SUPPLY
13 AWG cables
Fuse 1A
REM
18 AWG cable
REM (remote)
INPUT
A B
+ A
+ B
Ground
▪ Installaon must be done only by qualied professionals with the
product turned OFF.
▪ The use of fuse is mandatory to protect the system from short
circuit and overload. Install them as close to the baery as possible.
