Tineco A10 HERO User Manual

Assembly
Install the Dustbin
Install the Battery
Install the dustbin to the main body and push
upward until a ‘click’ sound is heard.
Press the battery release button, then pull
the battery out.
Slide the battery into the bottom of the main body.
The battery will click into position when correctly fitted.
Press the dustbin release button and pull out.
8

Tineco A10 HERO Specifications

General

Product	Product Technical Parameters
Dustbin Capacity	0.4 L
Operating Voltage	21.6 V
Rated Power	350 W
Charge Time	<=5 hrs
Battery Model	A10 2000mAh 6INR 19/66
Continuous Working Time	25 min. (MAX mode: 7 min)
Adaptor	YLS0241A-T260080
Input	100-240V 50/60Hz 0.8A(MAX), 100-240V 50/60Hz 1.3A(MAX)
Dual Adaptor	TFDZ-18W07A2M

Weight and Dimensions

Dimensions	12.727.4030.24 in（ LWH）
Net Weight	2.87 lb (main body)
