Tineco A10 HERO User Manual

When finished, press the release button on the
side of the dustbin and empty the contents.
Reattach the dustbin's bottom cover.
Product Operation
10
Empty the Dustbin
Charging the Battery
Connect the adaptor to the battery pack.
Dual Adaptor can charge two battery packs at the same time.
To prevent any accident , please put away the appliance on the docking station near wall during
charging.
Please see page 14 for power rating information.
Note: A10 MASTER is equipped with Dual adaptor and two Battery packs.

Tineco A10 HERO Specifications

General

Product	Product Technical Parameters
Dustbin Capacity	0.4 L
Operating Voltage	21.6 V
Rated Power	350 W
Charge Time	<=5 hrs
Battery Model	A10 2000mAh 6INR 19/66
Continuous Working Time	25 min. (MAX mode: 7 min)
Adaptor	YLS0241A-T260080
Input	100-240V 50/60Hz 0.8A(MAX), 100-240V 50/60Hz 1.3A(MAX)
Dual Adaptor	TFDZ-18W07A2M

Weight and Dimensions

Dimensions	12.727.4030.24 in（ LWH）
Net Weight	2.87 lb (main body)
