TINY Hawk II Freestyle User Manual

4
emax-usa.com
Product specification
Tinyhawk II Freestyle
Parameter
Diagonal wheelbase (without paddles)
115mm
Maximum size of the aircraft (without
antenna, cable tie)
143×137×23(mm)
Aircraft weight (without battery)
57g
Motor
TH1103-7000KV
Propeller
Avan Rush 2.5 inch Propeller
Main Flight Controller
F4
（
MATEKF411RX firmware
）
4 in one 5A ESC
SPI RX receiver
（
Compatible with Frsky remote
control D8 mode）
Camera
RunCam Nano 2 Camera
Transmitter
0-25-100-200mW Adjustable frequency 37CH.
Support SmartAudio. Ham radio license required for
use in North America.
Battery
1 Cell 450 mAh HV lipo battery ×2
Radio
Maximum appearance size
181×213×80(mm)
weight (without battery)
211g
Number of channels
6 Channels
Transmission frequency
2.4GHz ISM Band
（
2400MHz~2483.5MHz
）
Output Power
22dbm
Modulation
GFSK
battery
1 cell 18650 lipo battery
