Tisira TOC969E - Cleaning and Mounting Oven Door

Page
16
Electric Oven
User Manual
Cleaning and mounting oven door
Figure 8 Figure 9
Figure 8.1 Figure 8.2 Figure 9.1 Figure 9.2
Perform instructions in reverse to reinstall oven door back.
Set the hinge lock to
the widest angle as in
Figure 8.2. Adjust both
hinges connecting oven
door to the oven to the
same position.
Open the door fully by
pulling the oven door
toward yourself. Then
perform unlock
operation by pulling
the hinge lock
upwards with the aid
of screwdriver as
indicated in
Figure 8.1 .
Later, close the opened
oven door so that it will
be in a position to
contact with hinge lock
as in Figure 9.1.
For easier removal of
oven door, when it
comes close to
closed position, hold
the cover with two
hands as in Figure
9.2
and pull upwards.
