TiSUN SIMPLEX - Product Characteristics; Technical Specifications

5
MAIN CHARACTERISTICS
LED display.
Easy use interface (3 keys).
3 Inputs for temperature sensors (PT1000 type)
1 output for main pump.

Automatic, Off or Manual test mode.
Sensors Auto checks (Short circuit and breaks)
Collector type choice (Tube or panel)
Collector protection (Freeze and over heat)
Permanent memory storage
TECHNICAL CHARACTERISTICS
Operating temperature
0°C  50°C
Electrical Protection
Installation Category
Pollution Degree
IP20
II
2
Fusible
Power supply
4AT 230Vac (5x20mm)
230Vac +/- 10% 50Hz
Outputs:
P1 (Main pump):
P2 (Extra, Additional heat,

Relay 2A 230VAC
Relay 2A 230VAC
Inputs:
T1 (Collector1):
T2 (Tank1):
T3 (Extra sensor):
PT 1000 type
PT 1000 type
PT 1000 type
Software version
Displayed during the init
Version x.xx
