Cable connection:
* Note: If the power cable or signal cable is damaged, you must replace it
* The bottom interface conguration at the back of the monitor varie with
products.
with special soft cables or special components purchased from the
manufacture or maintenance department.
Please connect the power
cable plug to the
corresponding port of the
monitor, and connect the
other end to a properly
grounded power outlet.
Use the HDMI cable to connect the HDMI IN interface
of the product to the HDMI OUT interface of a PC.
HDMI interface
Use the HDMI-DVI cable to connect the HDMI IN interface
of the product to the DVI OUT interface of a PC.
(In general, PCs do not transfer video signals to the
monitor through the DVI OUT interface , and it is
necessary to connect a loudspeaker box additionally to
play sounds of PCs.)
DP interface
AC IN
AUDIO OUT
OR
Use the DP cable to
connect the DP IN interface
of the product to the DP
OUT interface of a PC.
Connect audio outputting
devices such as earphones
to the AUDIO OUT
interface.
