4
Main Parts
No.
Part Name
No.
Part Name
No.
Part Name
1
Oil Level Gauge
2
Handle
3
Starter
4
Gas Tank
5
Gas Cap
6
Choke Valve
7
Fuel Bubble
8
Air Filter
9
Positioning Sleeve
10
Dampening Spring
11
Handle Sleeve
12
Grease Cap
13
Hammer Case
14
Serial No. Location
15
Throttle Limit Screw
16
Combination Switch
17
Throttle Switch
18
Stop Switch
19
Throttle Cable
20
Piling Socket
21
Piling Socket Sleeve
