TTB671VAC by TITAN
Before you start
Getting
EN
13
Base
>
> Align and attach the castors (8) onto the base (6). Push the castors (8) all the
way to the stop.
> Align the markings “1” / “2” and assemble the wheels (7) onto the base (6).
Secure the connection with the screws (7a) (Fig. 1).
8
7
7a
6
Fig. 1
> Turn the assembled main body with the wheels (7) / castors (8) right way up
Dust collection
NOTE:
Use the dust bag to achieve better performance and easy maintenance
disposal of dust and cleaning collection container etc.) if required.
> Place the dust bag (24) into the collection container (9).
> Ensure the dust bag (24) is properly attached on the inner opening of the
intake (10) (Fig. 2).
10
24
9
Fig. 2
