Titan TTB671VAC - Page 15

TTB671VAC by TITAN
Before you start
Getting
started...
EN
15
Suction hose and tube
> Insert the hose connector (11) into the outer opening of the intake (10) all the
way to the stop. Ensure it is properly secured (Fig. 5).
1011
Fig. 5
>
necessary. Use the suction tube(s) with different accessories according to the
intended application.
WARNING! Do not use the suction tube(s) (14) when using the product
connected with a power tool as dust extraction device! The power tool
adaptor (23) shall be connected directly onto the suction handle (13).
> Connect the desired accessory onto the suction tube (14) / suction handle (13)
(Fig. 6).
21
15
14
13
22
23
21
22
Fig. 6
> Press the release button (10a) and keep it in position to disconnect the hose
connector (11) from the intake (10) after use (Fig. 7).
