Titan TTB671VAC - Page 20

TTB671VAC by TITAN
Product functions
20
EN
In more detail...
EN
Dust bag
> Switch the product off and disconnect it from the power supply.
>
the collection container (9) (Fig. 11).
> Disconnect the dust bag (24) from the inner opening of the intake (10) and
remove it carefully from the collection container. Install a new one afterward.
10
4
9
25
5
24
1.
4.
2.
3.
Fig. 11
>
Adjusting suction power
Adjust the suction power according to the
intended application (Fig. 12).
> Slide the suction power control (13a)
forward (as seen from operator’s
position) to increase the suction power.
> Slide the suction power control (13a)
backward (as seen from operator’s
position) to decrease the suction power.
13
13a
+
-
Fig. 12
