Titan TTB820GGT User Manual

EN
14
TTB820GGT by TITAN
Getting started...
Your product
Your product
1. Main handle
2. On/off switch
3. Power cord with plug
4. Rear safeguard
5. Cord retainer
(rotatable)
6. Upper pole
7. Unlock button for
angle adjustment
8. Locking sleeve for
length adjustment
9. Lower pole
a. Cord retainer
(xed)
10. Unlock button for tilt
adjustment
a. Indicator*
b. Indication line*
11. Guard
a. Screw
b. Knife
c. Screw hole*
d. Knife protector*
12. Trimmer head
a. Cover
b. Release latch (x2)
c. Trimming spool
d. Trimming line (x2)
e. Housing
f. Sliding slot (x2)*
g. Release push
button
h. Eyelet
i. Screw hole*
13. Plant protector
14. Motor housing
a. Edger support
15. Auxiliary handle
a. Lock button
16. Edger wheel
a. Release button
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
15
15a
13
14
14a
9a
9
8
7
6
5
4
3
2
1
10
11
12
16
16a
12a
12b
12c
12d
12e
11b
12g
11a
12h

Titan TTB820GGT Specifications

General

Brand	Titan
Model	TTB820GGT
Category	Trimmer
Language	English
