Your product
1 2
4
5
6
7
10
8
111215 14
1617181920
13
6a
6b
21
3
1. Lubrication hole (on both sides)
2. Guide bar
3. Saw chain
4. Front hand guard (with chain brake)
5. Front handle (for left hand)
6. Top cover
6a. Spark plug connector
6b. Air lter
7. Choke knob
8. Throttle trigger lock-out
9. Rear handle (for right hand)
10. Throttle trigger
11. Stop switch
12. Fuel tank cap
13. Adjusting screws for carburetor
14. Recoil starter handle
15. Oil tank cap
16. Spiked bumper
17. Chain catcher
18. Fixing nuts
19. Chain tension adjuster
20. Clutch cover
21. Primer
