19
TTCSP49
Getting Started . . .
1. Pull the front hand guard (4) backwards to disengage the chain brake (Fig. 1).
1
4
2. Loosen the xing nuts (18) using the multi-tool (24) and remove the clutch
cover (20) (Fig. 2).
Ensure the spiked bumper (16) is properly xed to the product. Tighten the 2 bolts
if necessary.
2
18
24
20
16
Before you start
