21
TTCSP49
Getting Started . . .
7.
Ret the clutch cover (20) and fasten using the xing nuts (18) and the multi-tool (24).
To t the clutch cover, align the tensioner pin with the lower hole on the guide bar (2)
by turning the chain tension adjuster (19) clockwise or anti-clockwise with the multi-
tool (24) (Fig. 6).
NOTE: Tighten the xing nuts (18) nger tight only at this stage. The chain
tension cannot be adjusted with the xing nuts fully tightened.
20
18
24
19
6
Tightening the saw chain
Always check the saw chain tension before use, after the rst cuts and regularly during
use, approx. every ve cuts. Upon initial operation, new chains can lengthen considerably.
This is normal during the break-in period and the interval between future adjustments
will lengthen quickly.
Before you start
