TTI821GGT by TITAN
Getting started...
Your product
1. Main handle
2. Lock-off button
3. On/off switch
4. Rear safeguard
5. Battery docking port
6. Upper pole
7. Unlock button for
angle adjustment
8. Locking sleeve for
length adjustment
9. Lower pole
10. Unlock button for tilt
adjustment
a. Indicator*
b. Indication line*
11. Guard
a. Screw
b. Knife
c. Screw hole*
d. Knife protector*
12. Plant protector
13. Trimmer head
a. Cover
b. Release latch (x2)
c. Trimming spool
d. Trimming line
e. Housing
f. Sliding slot (x2)*
g. Release push
button
h. Eyelet
i. Screw hole*
14. Motor housing
15. Auxiliary handle
a. Lock button
16. Battery pack
a. Battery capacity
indicators
b. Battery capacity
button
c. Release button
17. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
Your product / Before you start
