Titan TTI932CHN - Page 27

TTI932CHN
27
Getting
started...
EN
15
Fig. 10
NOTE:
Towards the end of the season, it is advisable to put only
as much lubricant in the tank as you need for each cut, so that it is
completely used up before you store the product.
5. Check the oil level window (15) prior to start-up and regularly during
operation. Rell oil when the oil level is close to the bottom of the oil level
window (15) (Fig. 10).
6. Wipe up spilled lubricant with a soft cloth and ret the oil tank cap (2).
NOTE:
Always dispose of lubricant, used oil and objects
contaminated with them in accordance with local regulations.
Checking
NOTE:
Perform the following test before operating your product.
This product is equipped with an automatic oiling system. The oiling
system automatically delivers the proper amount of oil to the bar
and chain.
Checking the lubrication requires starting the product. Before
checking, the product must be fully assembled and all instructions
must have been read.
1. Make sure the guide bar (12) and the saw chain (11) are in place when you
check the oil delivery.
2. Start the product; keep it running at no load and check if the chain oil is
delivered as shown in the gure (Figs.11, 12).
Fig. 11 Fig. 12
Before you start
