Chapter 4 Installation
14 AI5TV Motherboard User’s Manual
Chapter 4 Installation
This chapter describes the connectors and interface that the AI5TV
provides for creating a working system. Refer to Figure 3 for the
location of the connectors.
The following items are covered in this chapter:
J2: Keyboard Connector Page 16
J4: PS2 Mouse Connector Page 16
J7: Power Supply Connector Page 17
I/O Connector Page 18
J14: Front Bezel Connectors Page 18
J21: CPU Fan Power Connector Page 18
J20: IR Connector Page 19
J27, J28: USB Connectors Page 19
