Chapter 2 Hardware Description
AI5TV Motherboard User’s Manual 3
Chapter 2 Hardware Description
This chapter briefly describes each of the major features of the AI5TV
system board. The layout of the board is shown in Figure 1 which
shows the locations of key components. The topics covered in this
chapter are as follows:
2.1 Processor Page 5
2.2 L2 Cache and Cache Module Connector Page 5
2.3 Main Memory Page 6
2.4 BIOS Page 7
2.5 I/O Port Address Map Page 8
2.6 DMA Channels Page 8
2.7 Interrupt Request Page 9
2.8 Onboard PCI-EIDE Page 9
2.9 Onboard Multi-I/O Page 9
