Chapter 5 BIOS
34 AI5TV Motherboard User’s Manual
PNP/PCI Configuration
This option configures the PCI bus system. All PCI bus systems on the
system use INT#, thus all installed PCI cards must be set to this value.
ROM PCI/ISA BIOS
CHIPSET FEATURES SETUP
AWARD SOFTWARE INC.
Resources Controlled by : Manual PCI IRQ Activated By : Level
Reset Configuration Data : Disable PCI IDE IRQ Map to : PCI-Auto
Prinary IDE INT# : A
IRQ-3 assigned to : Legacy ISA Secondrary IDE INT# : B
IRQ-4 assigned to : Legacy ISA
IRQ-5 assigned to : PCI/ISA PnP
IRQ-7 assigned to : Legacy ISA
IRQ-9 assigned to : PCI/ISA PnP
IRQ-10 assigned to : PCI/ISA PnP
IRQ-11 assigned to : PCI/ISA PnP
IRQ-12 assigned to : PCI/ISA PnP
IRQ-14 assigned to : Legacy ISA
IRQ-15 assigned o : Legacy ISA
DMA-0 assigned to : PCI/ISA PnP
DMA-1 assigned to : PCI/ISA PnP
DMA-2 assigned to : PCI/ISA PnP
DMA-3 assigned to : PCI/ISA PnP ESC : Quit á â à ß : Select Item
DMA-4 assigned to : PCI/ISA PnP F1 : Help PU/PD/+/- : Modify
DMA-5 assigned to : PCI/ISA PnP F5 : Old Values (Shift) F2 : Color
DMA-6 assigned to : PCI/ISA PnP F6 : Load BIOS Defaults
DMA-7 assigned to : PCI/ISA PnP F7 : Load Setup Defaults
Resources Controlled by
This PnP BIOS can configure all of the boot and compatible devices
automatically. However, this capability needs you to use a PnP
operating system such as Windows 95. The default value is Manual.
Reset Configuration Data
This field allows you to determine whether reset the configuration data
or not. The default value is Disabled.
IRQ3/4/5/7/9/10/11/12/14/15, DMA0/1/3/5/6/7 assigned to
These fields allow you to determine the IRQ/DMA assigned to the ISA
bus and is not available to any PCI slot.
PCI IRQ Activated by
This field allows you to select the method by which the PCI bus
recognizes that an IRQ service is being requested by a device. The
default value is Level.
