Chapter 4 Installation
18 AI5TV Motherboard User’s Manual
J7: Power Supply Connector
When using an AT compatible power supply, plug both of the power
supply connectors into J7.
Make sure the power supply connectors are connected in the right
orientation. The power supply connectors are connected in the right
orientation if the black wires of each power cable are ADJACENT to
each other. That is, black wires of each connector should be aligned in
the center of the power supply connectors, J7, of the AI5TV.
The following table indicates the pin-out assignments of the power
supply connectors.
J7 Pin # Description Wire Color
1
Θ
Power Good Orange
2
l
+5V Red
3
l
+12V Yellow
4
l
-12V Blue
5
l
Ground Black
6
l
Ground Black
7
Θ
Ground Black
8
l
Ground Black
9
l
-5V White
10
l
+5V Red
11
l
+5V Red
12
l
+5V Red
