TMC V2Skim Series User Manual

1
2
17
16
3
4
7
9
10
12
14
15
11
13
PARTS LI ST
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(mm)
I
(mm)
J
(mm)
K
(mm)
V
2
Skim 400
435 120 85 255 110 185 105 250 17 50 60 160
V
2
Skim 600
510 135 105 285 130 230 165 283 20 50 80 180
V
2
Skim 800
510 180 125 225 160 285 185 225 30 50 102 205
V
2
Skim 1000
610 180 125 325 160 285 185 325 30 50 102 205
V
2
Skim 1200
540 200 150 225 190 320 215 225 30 50 117 230
V
2
Skim 1500
640 200 150 325 190 320 215 325 30 50 117 230
A
(mm)
L
(mm)
24
Outlet hose assembly = 290mm long
Inlet pipe hose assembly = 330mm long
8
see
p.4
*
18
20
22
23
21
19
2
1. Collection Cup Lid
2. Collection Cup
3Water Level Adjustment Dial
4. Water Outlet
5. Outlet Pipe Assembly (part no. 5366)
6. Inlet Pipe Hose Assembly (part no. 5365)
7. Water Inlet
8. V
2
Skim Securing Screws (part no. 5369 - sold separately)
9. Main Skimmer Body
10. Venturi Injection Assembly
11. Venturi Air Inlet Connection Tube (on models 800-1500 only)
(part no. 5370)
12, Hanger
13. Venturi Air Intake Silencer (on models 800-1500 only)
14. Air Inlet
15. Collection Cup O Ring (on models 600-1500 only) (part no. 5364)
16. Drain Port (on models 800-1500 only)
17. Collection Cup Cone
13
DIMENSIONS
Footprint
Hanger
E
H
J
D
A
G
F
B
L
C
K
To p v i e w
Side view
6
5
18. V
2
Bubble Stop Black Sponge Filter
(models 400-600 - part no. 5360/models 800-1500 - part no. 5362)
19. V
2
Bubble Stop White Sponge Filter
(model 400-600 - part no. 5361/models 800-1500 - part no. 5363)
20. V
2
Bubble Stop
21. V
2
Bubble Stop Mounting Bracket option 1
22. V
2
Bubble Stop Mounting Bracket option 2
23. V
2
Bubble Stop Securing Screw (part no. 5368)
24. Collection Cup Drain Hose (on models 800-1500 only) (part no. 5367)
