TMT HUSKY700 - Gate Operation Commands

5.4 Gate Operation
Press the button “A” on the transmitter for dual-gate operation.
Press the button “B” on the transmitter for single-gate
operation in either single-gate or dual-gate installation.
5.5 Gate-moving Logic
(A) In gate-opening phase: The gates stop if the transmitter/push button/key selector is activated, and close when
the transmitter/push button/key selector is reactivated.
(B) In gate-closing phase: The gates stop if the transmitter/push button/key selector is activated, and open when
the transmitter/push button/key selector is reactivated.
(C) In gate-opening or gate-closing phase: For safety purpose, the gates stop if encountering obstacles.
6). TECHNICAL CHARACTERISTICS:
6.1 Techanical Data Sheet of Series
AC230V 50Hz
700kg
17.4cm/sec
Spring/Magnetic
-20°C to +65°C
IP 54
700kg level
AC230V 50Hz
500kg
17.4cm/sec
Spring/Magnetic
-20°C to +65°C
IP 54
500kg level
AC230V 50Hz
1000kg
17.4cm/sec
Spring/Magnetic
-20°C to +65°C
IP 54
1000kg level
HUSKY700HUSKY500 HUSKY1000
Specifications
Power supply
Gate Weight
Gate speed
Limit switch
Temperature
Protection class
6.2 TM3 Transmitter Data Sheet
Application
Frequency
Coding
Buttons
Power Supply
Operating Temperature
Dimension
Radio transmitter
433.92Mhz
Rolling code
4, for single-gate or dual-gate operation
3V with one CR2032 button type lithium battery
-20℃~+50℃
71.5mm * 33mm * 14mm
HUSKY SERIES SLIDING GATE OPENER USER MANUAL
9
A B
