12. SPECIFICATIONS
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (2P)
....................1
Removable terminal plug (3P)
....................2
Removable terminal plug (4P)
....................1
AC power cord
.....................................1
Rubber foot
.........................................4
EMT adaptor plate
.................................1
Model No.
AV-20D
Power Source
100V-240V AC , 50Hz/60Hz
Rated Output 15W x 2 @ 8 Ohms,20W x 2 @ 4 Ohms,40W x 1 @ 8 Ohms (Bridge)
Rated Output
63W
Idle Less than 6W
Power Consumption
Power Save Mode
Less than 1W
Frequency Response
20Hz to 20KHz
±
3dB (Line1 input with transformer:100Hz to 20KHz)
Total Harmonic Distortion (THD+N) Less than
0.15%
Line 1:
–10/-20dB* (selectable), 10 K Ohms, transformer-balanced,
removable terminal block
Line 2:
–10/-20dB* (selectable), 10 K Ohms, unbalanced, 3.5mm stereo jack
Input
Line 3:
–10/-20dB* (selectable), 10 K Ohms, unbalanced, RCA jacks
Output Speaker Output, Removable terminal block (4P)
Tone Control Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
Controls Master volume control
Remote volume control
Bass tone control, Treble tone control
Bridge ON/OFF Switch
Mono/Stereo switch
Input sensitivity switches (Line 1, Line 2, Line 3)
Indicator
Power LED, Protection LED, Signal LED, Peak LED
Other Feature Automatic Level Control,Thermal/Over-current protection
Operating Temperature
-10 to +40°C
Case
Black metal case
Dimensions 150 (w) x 44 (h) x 156 (d) mm (5.90" x 1.73" x 6.14")
Weight 1.00 Kg (2.2 Ibs)
