Toa F-2000BTWP User Manual

18
F-2000BT F-2000WT
Bass-reflex type
60 W (high impedance)
Continuos pink noise: 60 W (low impedance)
Continuos program: 180 W (low impedance)
8 Ω,
100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 3.3 kΩ (3 W)
70 V line: 83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 3.3 kΩ (1.5 W)
92 dB (1 W, 1 m) at installation in a semianechoic field
93 dB (1 W, 1 m) at installation in a semianechoic field (with horn adapter)
65 – 20,000 Hz, –10 dB at installation in a semianechoic field
2.5 kHz
Horizontal: 110º, Vertical: 100º
Horizontal: 80º, Vertical: 80º (with horn adapter)
Woofer: 20 cm cone-type
Tweeter: 25 mm dome-type
Push-in terminals
HIPS, black HIPS, white
Surface-treated steel plate, black, paint Surface-treated steel plate, white, paint
Aluminum die-cast, black, paint Aluminum die-cast, white, paint
Steel plate, t2.0, black, paint Steel plate, t2.0, white, paint
244 (w) x 373 (h) x 235 (d) mm
7.4 kg (including the supplied brackets)
Speaker bracket ... 1, Joint bracket ... 1, Wall bracket ... 1, Fixing bolt M6 x 85 ... 1,
Hexagon bolt M6 x 12 (with plain washer and spring washer) ... 2,
Machine screw M5 x 20 (with plain washer and spring washer) ... 4,
Tapping screw 4 x 12 ... 4, Horn adapter ... 1
Ceiling mount bracket: HY-CM20B Ceiling mount bracket: HY-CM20W
Cluster bracket: HY-CL20B Cluster bracket: HY-CL20B
Speaker stand: ST-16A Speaker stand: ST-16A
Model No.
Enclosure Type
Rated Input
Power Handling Capacity
Rated Impedance
Output Sound Pressure
Level
Frequency Response
Crossover Frequency
Directivity Angle
Speakers
Input Terminals
Enclosure
Mesh Speaker Grill
Speaker Bracket
Joint Bracket, Wall Bracket
Dimensions
Weight
Accessories
Optional Products
Note: The design and specifications are subject to change without notice for improvement.
11.2. F-2000BT and F-2000WT
