Toa F-2000BTWP User Manual

19
F-2000BTWP F-2000WTWP
Bass-reflex type
60 W
100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 3.3 kΩ (3 W)
70 V line: 83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W), 3.3 kΩ (1.5 W)
92 dB (1 W, 1 m) at installation in a semianechoic field
93 dB (1 W, 1 m) at installation in a semianechoic field (with horn adapter)
65 – 20,000 Hz, –10 dB at installation in a semianechoic field
2.5 kHz
Horizontal: 110º, Vertical: 100º
Horizontal: 80º, Vertical: 80º (with horn adapter)
Woofer: 20 cm cone-type
Tweeter: 25 mm dome-type
Push-in terminals
IPX4
–10 ºC to +50 ºC
HIPS, black HIPS, white
Surface-treated steel plate, black, Surface-treated steel plate, white,
anti-rust paint anti-rust paint
Aluminum die-cast, black, paint Aluminum die-cast, white, paint
Stainless steel, t2.0
244 (w) x 373 (h) x 235 (d) mm
7.4 kg (including the supplied brackets)
Speaker bracket ... 1, Joint bracket ... 1, Wall bracket ... 1, Fixing bolt M6 x 85 ... 1,
Hexagon bolt M6 x 12 (with plain washer and spring washer) ... 2,
Machine screw M5 x 20 (with plain washer and spring washer) ... 4,
Tapping screw 4 x 12 ... 8, Horn adapter ... 1, Terminal cover ... 1
Pole mount bracket: SP-131
Pole band: YS-60B
Model No.
Enclosure Type
Power Handling Capacity
Rated Impedance
Output Sound Pressure
Level
Frequency Response
Crossover Frequency
Directivity Angle
Speakers
Input Terminals
Water Resistance
Operating Temperature
Enclosure
Mesh Speaker Grill
Speaker Bracket
Joint Bracket, Wall Bracket
Dimensions
Weight
Accessories
Optional Products
Note: The design and specifications are subject to change without notice for improvement.
11.3. F-2000BTWP and F-2000WTWP
