7. OUTDOOR USE (H-2WP ONLY)
7.1. Waterproofing
The H-2WP's base frame has a gasket for watertightness.
To completely prevent water from getting into a gap
between the base frame and wall or ceiling panel, apply
caulking agent over the inside of the gasket before
mounting the base frame.
7.2. Speaker Mounting Angle
When mounting the H-2WP speaker on a wall, to ensure
its watertightness it must not be tilted any more than 45
degrees up from its downward-facing position.
Notes
• The H-2WP features drip-proof construction. However,
do not dash water over it when cleaning as this may
cause damage to the speaker components.
• When installing the H-2WP outdoors in a snowy area,
protect the speaker so that it is not covered with snow.
Gasket
Caulking agent
10
