Step 2. MounteyeboltstotheT-bracket.
TheT-brackethasthreeM8eyeboltmountingholes.
Be sure to install the eyebolts in these 3 places.
Note
Eyeboltsarenotsuppliedwiththebracket.Preparethemseparately.
Step 3. Attachthesuspensionwirestotheeyebolts,andsuspendthespeakerat3pointsusingchains,anchor
shackles, etc.
Wire
Eyebolt
2
2
2
3
3
3
Tightening torque:
8 N·m
Step 4. Mountthesafetywires.
Forthesafetywiremountingmethod,
refer to the operating instructions
supplied with the HX-7B or HX-7W
speaker.
Carefullynotethefollowinginstructionsinordertoprevent
accidentaldroppingofthespeakers,whichcouldpotentially
resultinpersonalinjury.
• Donotjointogetherandsuspend5ormoreHX-7BorHX-
7Wspeakerunitsinasinglecluster.
• Ensurethattheinstallationlocationisstructurallycapable
of supporting the weight of the speakers and their
mounting brackets.
• Use eyebolts, cables, chains and anchor shackles that
can sufciently support the weight of the speakers and
their speaker mounting brackets.
• When suspending speakers as shown at left, limit the
numberofjoinedspeakersto2unitsorless.
• When suspending 3 or 4 joined speakers, be sure to
suspendthespeakersfrom5ormorepoints,distributing
theloadequallytoeachcable.InadditiontotheT-bracket
and 3-pointsuspension system,also attachcablesto2
placesatthelowerportionofthejoinedspeakersinorder
to pull up the speakers from their lower part.
WARNING
