5. SUSPENDING THE SPEAKER FROM A CEILING (only the T-bracket is used)
TheHX-7BorHX-7WSpeakerSystemcanbesuspendedfromaceilingbyonlyusingtheT-bracket.
Note
Similarly, fix the T-bracket to the end of the
side angle plate on the opposite side.
HX-7B or HX-7W
T-bracket
Spacer ø9.2 (0.36")
(accessory)
Rear bracket
Hex head
bolt M6x12
(accessory)
Side angle plate
Protection cover
Note
Remove the
protection covers
from the side
angle plates
before joining.
1-1
Tightening torque:
5 N·m
J-spacer
(accessory)
1-2
(1) Lightly secure.
(3) Tighten firmly.
(2) Insert.
Flange nut for M6
(accessory)
Hex head
bolt M6x30
(accessory)
Tightening torque:
5 N·m
Tightentheboltssecurely,asinstructedbelow.
Failureto follow instructions precisely could result in a falling speaker
andpotentialpersonalinjury.
• Ensurethatallboltsaresecurelyinsertedasfarastheirthreadsgo,
then securely fasten each bolt with a nut.
• Tightenalltheboltswiththedesignatedtighteningtorque.
 Fortightening,useaPhillipsscrewdriver,oropen-orbox-endwrench.
WARNING
Step 1. Attach the T-bracket to the speaker.
Attachwiththespeakersetaboveasshowninthegure.
FixtheT-brackettothespeakeratall3indicatedpositions.
1-1. FixtheT-brackettobothendsofthesideangleplatesofthespeakerfront.
Usethesuppliedbolts(withspringandplainwashers)andspacers.
1-2. FixtheT-brackettothespeaker’srearbracket.
Fixtotherearbracket’sendmosthole.
Usethesuppliedbolt(withspringandplainwashers),J-spacer,andangenut.
Fordetails,refertotheprocedures(1)to(3)asshownbelow.
Note
After tightening the bolt, ensure
thattheJ-spacerisrmlyxed.
