6. DIRECT SPEAKER CEILING MOUNTING (only the T-bracket is used)
AsingleHX-7BorHX-7WSpeakerSystemcanbemountedtoceilingsorbeamsbyonlyusingtheT-bracket.
Note
OnlyoneHX-7BorHX-7Wspeakercanbemounted.Twojoinedspeakerscannotbemounted.
Step 1. MounttheT-brackettotheceilingorbeamusingbolts,etc.
Ceilingorbeammountingboltsandnutsarenotsupplied.
Use nuts and bolts that are appropriate for the ceiling’s or
beam’sstructureandcomposition.Failuretodosomaycause
thespeakertofall,resultinginpersonalinjury.
WARNING
[Mounting dimensions]
Unit:mm
(Front) (Right side)
353 (13.9")
60 (2.36")164.5 (6.48")
0
20 (0.79")
70 (2.76")
120 (4.72")
170 (6.69")
220 (8.66")
0
430 (16.93")
270 (10.63")
320 (12.6")
370 (14.57")
20 (0.79")
70 (2.76")
120 (4.72")
170 (6.69")
220 (8.66")
270 (10.63")
320 (12.6")
370 (14.57")
ø9 (0.35")
(with M8 weld nut)
ø9 (0.35")
(with M8 weld nut)
ø9 (0.35")
(with M8 weld nut)
ø8.5 (0.33")
(16 positions)*
ø8.5 (0.33")
(14 positions)*
Note: Left-side surface same.
*TheseholesnotttedwithM8weldnuts.
